Doughty Heavy Duty Pulley, Triple Sheave, for Wire or Rope
A basic triple sheave pulley ready to accept any of our Doughty range of fixings.
Available from 100mm Diameter to 200mm Diameter, for Wire or Rope.
The recommended sizes and for Hand Ropes & Wires are:
100mm Diameter Sheave - 12mm Rope – 4mm Wire
150mm Diameter Sheave - 18mm Rope – 6mm Wire
200mm Diameter Sheave - 18mm Rope – 6mm Wire
Spec
SKU 300-54-3: 100mm (triple sheave) for wire - SWL 200 Kg
SKU 300-55-3: 150mm (triple sheave) for wire - SWL 400 Kg
SKU 300-56-3: 200mm (triple sheave) for wire - SWL 600 Kg
SKU 300-57-3: 100mm (triple sheave) for rope - SWL 200 Kg
SKU 300-58-3: 150mm (triple sheave) for rope - SWL 400 Kg
SKU 300-59-3: 200mm (triple sheave) for rope - SWL 600 Kg
