SKU |
Cyl. Cap. | Stroke | Cyl. Effective Area | Oil Cap. | Retracted Height | Extended Height | Cyl. Out Dia | Cyl. Bore Dia | Piston Rod Dia | Base to Inlet Port | Weight | Pump |
---|---|---|---|---|---|---|---|---|---|---|---|---|
t | mm |
cm2
|
cc | A mm | B mm | C mm | D mm | E mm | F mm | kgs | ||
286-706-1 |
20 | 50 | 28.3 | 145 | 150 | 200 | 89 | 60 | 54 | 28 | 3.2 | 1B or 08 |
286-706-2 |
20 | 100 | 28.3 | 290 | 200 | 300 | 89 | 60 | 54 | 28 | 4.1 | 1B or 08 |
286-706-3 |
20 | 150 | 28.3 | 435 | 250 | 400 | 89 | 60 | 54 | 28 | 4.8 | 1B or 08 |
286-706-4 |
30 | 50 | 44.2 | 220 | 168 | 218 | 108 | 75 | 65 | 35 | 5 | 1B or 08 |
286-706-5 |
30 | 100 | 44.2 | 440 | 218 | 318 | 108 | 75 | 65 | 35 | 6.3 | 1B or 08 |
286-706-6 |
30 | 150 | 44.2 | 660 | 268 | 418 | 108 | 75 | 65 | 35 | 7.5 | 1C or 17 |
286-706-7 |
50 | 50 | 70.9 | 355 | 182 | 232 | 134 | 95 | 85 | 35 | 8.7 | 1B or 08 |
286-706-8 |
50 | 100 | 70.9 | 708 | 232 | 332 | 134 | 95 | 85 | 35 | 10.2 | 1C or 17 |
286-706-9 |
50 | 150 | 70.9 | 1,063 | 282 | 432 | 134 | 95 | 85 | 35 | 12.9 | 1C or 17 |
286-706-10 |
100 | 50 | 132.8 | 660 | 193 | 243 | 189 | 130 | 110 | 40 | 16.5 | 1C or 17 |
286-706-11 |
100 | 100 | 132.8 | 1,320 | 243 | 343 | 189 | 130 | 110 | 40 | 20.6 | 25 |
286-706-12 |
100 | 150 | 132.8 | 1,980 | 293 | 443 | 189 | 130 | 110 | 40 | 23.4 | 25 |
286-706-13 |
150 | 50 | 201.1 | 1,005 | 208 | 258 | 238 | 160 | 135 | 45 | 27 | 25 |
286-706-14 |
150 | 100 | 201.1 | 2,010 | 258 | 358 | 238 | 160 | 135 | 45 | 33.4 | 25 |
286-706-15 |
150 | 150 | 201.1 | 3,016 | 308 | 458 | 238 | 160 | 135 | 45 | 39.8 | 50 |
