YOKE Grade 100 Eye Grab Hook
- Quenched and Tempered Alloy Steel
- At least 25% greater WLL than traditional G80 products
- Manufactured in accordance with DIN PAS 1061, EN 1677-1 and ASTM A952/A 952M
- Certified by DGUV GS-OA-15-05
- Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
- Design Factor 4:1
- Fatigue rated to 20,000 cycles at 1.5 times the WLL
- Tempering temperature minimum 400°C
- Not for use with Omega Link
- Enables full WLL while in use, thanks to supporting wings which prevent chain link deformation
Spec
SKU |
Capacity (t) |
For Grade 100 Chain (mm) |
Weight (kg) |
276-60-1 |
2.5 |
6 |
0.4 |
276-60-2 |
4 |
7, 8 |
0.8 |
276-60-3 |
6.7 |
10 |
1.6 |
276-60-4 |
10 |
13 |
2.7 |
276-60-5 |
16 |
16 |
4.8 |
276-60-6 |
19 |
20 |
6.4 |
